FRAME |
Chase Element ProXXL 21.5" Top Tube 7005 T6 Alloy, Integrated Head Tube, 1-1/8", Close Drop Out |
|
FORK |
Chase Element ProXXL 21.5" Top Tube 7005 T6 Alloy, Integrated Head Tube, 1-1/8", Close Drop Out |
|
HEADSET |
Integrated IS 42/42 1-1/8", Sealed Bearing |
|
HANDLEBAR |
Chase Element Cromo 8.5", Diameter 31.8mm, Rise, 28.5" Wide, 10° Back Sweep & 2° Up Sweep |
|
GRIPS |
Insight C.O.G.S 145mm Alloy Clamps Laser Etched Logo, PVC End Plug |
|
STEM |
Chase Element 1-1/8" Steer Tube, Diameter 31.8mmmm, Length 53mm 6061 T6 Alloy CNC Laser Etched Logo |
|
BB |
Press Fit 68/73mm Cartridge Bearings |
|
CHAINRING |
Insight 44 Tooth 4 Bolt 104mm 1/2"x3/32" 5mm Alloy Ring |
|
CRANK |
Excess LSP 2 Piece Crank 180mm Alloy Arm, 4 Bolt Spider, Cr-mo Pedal Inserts, Alloy Chain Ring Bolts / Nuts |
|
PEDAL |
Nylon Platform Pedal 9/16" |
|
CHAIN |
KMC Z1 Narrow 1/2"x3/32" |
|
COG |
16 Tooth |
|
FRONT HUB |
Chase Element 3/8" Bolts, 36H, Sealed Bearing |
|
REAR HUB |
Chase Element Pro ISO Hub, 36H, Sealed Bearing, 3/8" Bolts, Steel Cassette Body with 3 Pawls at Triple Angle Engagement for 24T Ratchets |
|
SPOKES |
Front 186mm, Rear 181mm, 14 Gauge, Steel |
|
NIPPLES |
Brass 14Gx5/8" |
|
RIMS |
Sun Rims Alloy Envy Front 36H 20"x1.75" No Brake Surface Schrader Valve |
|
FRONT TIRE |
Tioga Fastr X 20"x1.85" 60 TPI Wire Bead |
|
REAR TIRE |
Tioga Fastr X 20"x1.65" 60 TPI Wire Bead |
|
TUBES |
20''x1.5"-1.75" Schrader Valve |
|
BRAKES |
Tektro HD-M280 Hydraulic, Resin Pads, 120mm Rotor |
|
SADDLE |
Elevn PC Pivotal |
|
SEAT POST |
CHASE Aero Pivotal 27.2x260mm Alloy |
|
SEAT CLAMP |
Chase Aero QR Alloy 31.8mm |
|
CHAIN TENSIONNER |
Integrated Built-In With New Lock Disc Adaptor |
