FRAME |
Chase Element Expert 20" Top Tube 7005 T6 Alloy, Integrated Head Tube, 1-1/8", Close Drop Out |
|
FORK |
Ikon Pro 20" Carbon, Alloy 1-1/8" Steer Tube, 20mm Drop Out with Adaptor 3/8" Axle, Alloy Top Cap |
|
HEADSET |
Integrated IS 42/42 1-1/8", Sealed Bearing |
|
HANDLEBAR |
Chase Element Alloy 5.75", Diameter 31.8mm, Rise, 26.25" Wide, 10° Back Sweep & 2° Up Sweep |
|
GRIPS |
Insight C.O.G.S 130mm Alloy Clamps Laser Etched Logo, PVC End Plug |
|
STEM |
Chase Element 1-1/8" Steer Tube, Diameter 31.8mmmm, Length 45mm 6061 T6 Alloy CNC Laser Etched Logo |
|
BB |
Press Fit 68/73mm Cartridge Bearings |
|
CHAINRING |
Insight 42 Tooth 4 Bolt 104mm 1/2"x3/32" 5mm Alloy Ring |
|
CRANK |
Excess LSP 2 Piece Crank 165mm Alloy Arm, 4 Bolt Spider, Cr-mo Pedal Inserts, Alloy Chain Ring Bolts / Nuts |
|
PEDAL |
Nylon Platform Pedal 9/16" |
|
CHAIN |
KMC Z1 Narrow 1/2"x3/32" |
|
COG |
16 teeth |
|
FRONT HUB |
Chase Element M6 Bolts ,28H, Sealed Bearing |
|
REAR HUB |
Chase Element Mini ISO, 28H, Sealed Bearing, M6 Bolts, Steel Cassette Body with 3 Pawls at Triple Angle Engagement for 24T Ratchets |
|
SPOKES |
Front 215mm, Rear 213mm, 14 Gauge, Steel |
|
NIPPLES |
Brass 14Gx5/8" |
|
RIMS |
Sun Rims Alloy ICI-1 28H 20"x1-3/8" No Brake Surface Presta Valve |
|
FRONT TIRE |
Tioga Fastr X 20"x1-3/8" 60 TPI Wire Bead |
|
REAR TIRE |
Tioga Fastr X 20"x1-3/8" 60 TPI Wire Bead |
|
TUBES |
20x1-3/8" presta valve |
|
BRAKES |
Tektro HD-M281 Hydraulic, Resin Pads, 120mm Rotor |
| SEAT |
ELEVN PC Pivotal |
|
SEAT POST |
CHASE Aero Pivotal 27.2x260mm Alloy |
|
SEAT CLAMP |
Chase Aero QR Alloy 31.8mm |
|
CHAIN TENSIONNER |
Integrated Built-In With New Lock Disc Adaptor |
